I took a pleasant 3 1/2 hr trip down to Wellfleet, MA, way out on the arm of Cape Cod, to meet Walter Baron of Old Wharf Dory Co. and see the first ever Drake 19 "in the flesh".

Walt of Old Wharf, boatbuilder on Cape Cod

The boat looked great to me. I was so pleased. Even as the designer, I was struck by how much boat there is; it is 19'2" LOA afterall. Designed to be an open water, cruising rowboat for one, the boat would also make an excellent tandem rowboat for rows in the harbor or in more open water.

Drake 19 rightside up.

The interior has two side tanks on either side of the sliding seat system. The tanks will help the boat be self rescuable, with some additional flotation in the ends, The rails slide right into precut holes in the frames of the boat. Everything fits just so.

Sliding seat system integrates into the CNC cut structure of the boat

After this build, and with a few months to finish out the drafting and writing of the manual, the boat will be available as a kit.

On the Drawing Board

New Drake 19 for tandem rowing, cruising and expeditions

For Fixed Seat or Sliding Seat Rowing

This new version of the Drake Rowboat -- my first design/build project -- really combines all that I have learned as a designer and rower and builder over the years. She is intended with the following brief:

-- fast, stable cruising rowboat

--capacity for two people and gear

--fixed or sliding seat capable

--can sleep aboard on platform under a tent

--sailing downwind is possible

Drake 19 modeled in Rhino

An important aspect of the boat is its simple sliding seat system : 7/8" o.d. stainless steel pipes run for and aft with 15" of separation on center. The pipes are integrate into the CNC cut structure. A plywood seat-roller floats over these pipes. Any oarlock system can be used, including leathered-round oars, Douglas oarloacks, C2 oarlocks, or the folding outriggers by Shaw and Tenney. However, I think for voyaging in open water that oar-on-gunwale will be the best way, using traditionally leathered oars in horn-oarlocks or to go with pinned oars. I do think 9-9 1/2' oars would be fine for experienced rowers, using folding outriggers to get the spread for the longer oars.

Midship section of the Drake 19 showing the sliding seat system.

The floorboards are show both sitting on the inner keel as floors and raised up and sitting on the pipes to make an over 8' long sleeping platform that finishes flush with the side tanks. These side tanks double as a sleeping platform and as flotation, making the boat self-rescuable in a capsize.

Keep posted for 3D work which starts very soon.
